22 Configuring Audit Policies

When you audit a role, Oracle Database audits all system privileges that are directly granted to the role.

You can audit any role, including user-defined roles. If you create a common unified audit policy for roles with the ROLES audit option, then you must specify only common roles in the role list. When such a policy is enabled, Oracle Database audits all system privileges that are commonly and directly granted to the common role. The system privileges that are locally granted to the common role will not be audited. To find if a role was commonly granted, query the DBA_ROLES data dictionary view. To find if the privileges granted to the role were commonly granted, query the ROLE_SYS_PRIVS view.

To create a unified audit policy to capture role use, you must include the ROLES clause in the CREATE AUDIT POLICY statement.

CREATE AUDIT POLICY audit_roles_pol
 ROLES IMP_FULL_DATABASE, EXP_FULL_DATABASE;

The CREATE AUDIT POLICY statement can audit roles in a multitenant environment.

Example 22-2 shows how to audit a predefined common role DBA in a multitenant environment.

CREATE AUDIT POLICY role_dba_audit_pol
 ROLES DBA
 CONTAINER = ALL;

AUDIT POLICY role_dba_audit_pol;

System privilege auditing audits activities that use a system privilege, such as READ ANY TABLE.

In this kind of auditing, SQL statements that require the audited privilege to succeed are recorded.

A single unified audit policy can contain both privilege and action audit options. Do not audit the privilege use of administrative users such as SYS. Instead, audit their object actions.

You can audit the use of almost any system privilege.

To find a list of auditable system privileges, you can query the SYSTEM_PRIVILEGE_MAP table.

For example:

SELECT NAME FROM SYSTEM_PRIVILEGE_MAP;

NAME
-------------
ALTER ANY CUBE BUILD PROCESS
SELECT ANY CUBE BUILD PROCESS
ALTER ANY MEASURE FOLDER
...

Similar to action audit options, privilege auditing audits the use of system privileges that have been granted to database users. If you set similar audit options for both SQL statement and privilege auditing, then only a single audit record is generated. For example, if two policies exist, with one auditing EXECUTE PROCEDURE specifically on the HR.PROC procedure and the second auditing EXECUTE PROCEDURE in general (all procedures), then only one audit record is written.

Privilege auditing does not occur if the action is already permitted by the existing owner and object privileges. Privilege auditing is triggered only if the privileges are insufficient, that is, only if what makes the action possible is a system privilege. For example, suppose that user SCOTT has been granted the SELECT ANY TABLE privilege and SELECT ANY TABLE is being audited. If SCOTT selects his own table (for example, SCOTT.EMP), then the SELECT ANY TABLE privilege is not used. Because he performed the SELECT statement within his own schema, no audit record is generated. On the other hand, if SCOTT selects from another schema (for example, the HR.EMPLOYEES table), then an audit record is generated. Because SCOTT selected a table outside his own schema, he needed to use the SELECT ANY TABLE privilege.

Several system privileges cannot be audited.

These privileges are:

• INHERIT ANY PRIVILEGE

• INHERIT PRIVILEGE

• TRANSLATE ANY SQL

• TRANSLATE SQL

The PRIVILEGES clause in the CREATE AUDIT POLICY statement audits system privilege use.

The CREATE AUDIT POLICY statement can audit users for ANY privileges.

Example 22-3 shows how to audit several ANY privileges of the user HR_MGR.

CREATE AUDIT POLICY hr_mgr_audit_pol
 PRIVILEGES DROP ANY TABLE, DROP ANY CONTEXT, DROP ANY INDEX, DROP ANY LIBRARY;

AUDIT POLICY hr_mgr_audit_pol BY HR_MGR;

The CREATE AUDIT POLICY statement can create an audit policy that uses a condition to audit a system privilege.

Example 22-4 shows how to use a condition to audit privileges that are used by two operating system users, psmith and jrawlins.

CREATE AUDIT POLICY os_users_priv_pol
 PRIVILEGES SELECT ANY TABLE, CREATE LIBRARY
 WHEN 'SYS_CONTEXT (''USERENV'', ''OS_USER'') IN (''psmith'', ''jrawlins'')'
 EVALUATE PER SESSION;

AUDIT POLICY os_users_priv_pol;

The UNIFIED_AUDIT_TRAIL data dictionary view lists system privilege audit events.

The following example, based on the unified audit policy os_users_priv_pol that was created in Example 22-4, shows a list of privileges used by the operating system user psmith.

SELECT SYSTEM_PRIVILEGE_USED FROM UNIFIED_AUDIT_TRAIL
 WHERE OS_USERNAME = 'PSMITH' AND UNIFIED_AUDIT_POLICIES = 'OS_USERS_PRIV_POL';

SYSTEM_PRIVILEGE_USED
----------------------
SELECT ANY TABLE
DROP ANY TABLE

Oracle Database provides administrative user accounts that are associated with administrative privileges.

Table 22-1 lists default administrative user accounts and the administrative privileges with which they are typically associated.

^Footnote 1

PUBLIC refers to the user PUBLIC, which is the effective user when you log in with the SYSOPER administrative privilege. It does not refer to the PUBLIC role.

The CREATE AUDIT POLICY statement can audit administrative users.

The CREATE AUDIT POLICY statement can audit the SYS user.

Example 22-5 shows how to audit grants of the DBMS_FGA PL/SQL package by user SYS.

CREATE AUDIT POLICY dbms_fga_grants
 ACTIONS GRANT
 ON DBMS_FGA;

AUDIT POLICY dbms_fga_grants BY SYS;

You can audit actions performed on specific objects, such as UPDATE statements on the HR.EMPLOYEES table.

The audit can include both DDL and DML statements that were used on the object. A single unified audit policy can contain both privilege and action audit options, as well as audit options set for multiple objects.

Auditing object actions can be broad or focused (for example, auditing all user actions or only a select list of user actions).

Table 22-2 lists the object-level standard database action options. Audit policies for the SELECT SQL statement will capture READ actions as well as SELECT actions.

The ACTIONS clause in the CREATE AUDIT POLICY statement creates a policy that captures object actions.

CREATE AUDIT POLICY my_simple_obj_policy
 ACTIONS SELECT ON OE.ORDERS, UPDATE ON HR.EMPLOYEES;

The CREATE AUDIT POLICY statement can audit actions on SYS objects.

Example 22-6 shows how to create an audit policy that audits SELECT statements on the SYS.USER$ system table. The audit policy applies to all users, including SYS and SYSTEM.

CREATE AUDIT POLICY select_user_dictionary_table_pol ACTIONS SELECT ON SYS.USER$;

AUDIT POLICY select_user_dictionary_table_pol;

The CREATE AUDIT POLICY statement can audit multiple actions on one object.

Example 22-7 shows how to audit multiple SQL statements performed by users jrandolph and phawkins on the app_lib library.

CREATE AUDIT POLICY actions_on_hr_emp_pol1
 ACTIONS EXECUTE, GRANT
 ON app_lib;

AUDIT POLICY actions_on_hr_emp_pol1 BY jrandolph, phawkins;

The CREATE AUDIT POLICY statement can audit both actions and privileges on an object, using a single policy.

Example 22-8 shows a variation of Example 22-7, in which all EXECUTE and GRANT statements on the app_lib library using the CREATE LIBRARY privilege are audited.

CREATE AUDIT POLICY actions_on_hr_emp_pol2
 PRIVILEGES CREATE LIBRARY
 ACTIONS EXECUTE, GRANT
 ON app_lib;

AUDIT POLICY actions_on_hr_emp_pol2 BY jrandolph, phawkins;

The CREATE AUDIT POLICY statement can audit all actions on a table.

You can use the keyword ALL to audit all actions. Example 22-9 shows how to audit all actions on the HR.EMPLOYEES table, except actions by user pmulligan.

CREATE AUDIT POLICY all_actions_on_hr_emp_pol
 ACTIONS ALL ON HR.EMPLOYEES;

AUDIT POLICY all_actions_on_hr_emp_pol EXCEPT pmulligan;

The CREATE AUDIT POLICY statement can audit all actions in the database.

Example 22-10 shows how to audit all actions in the entire database.

CREATE AUDIT POLICY all_actions_pol ACTIONS ALL;

AUDIT POLICY all_actions_pol;

The UNIFIED_AUDIT_TRAIL data dictionary view lists object action audit events.

For example:

SELECT ACTION_NAME, OBJECT_SCHEMA, OBJECT_NAME FROM UNIFIED_AUDIT_TRAIL
WHERE DBUSERNAME = 'SYS';

ACTION_NAME OBJECT_SCHEMA OBJECT_NAME
----------- ------------- ------------
SELECT      HR            EMPLOYEES

You can audit functions, procedures, PL/SQL packages, and triggers.

Auditing can affect dynamic VPD policies, static VPD policies, and context-sensitive VPD policies.

• Dynamic policies: Oracle Database evaluates the policy function twice, once during SQL statement parsing and again during execution. As a result, two audit records are generated for each evaluation.

• Static policies: Oracle Database evaluates the policy function once and then caches it in the SGA. As a result, only one audit record is generated.

• Context-sensitive policies: Oracle Database executes the policy function once, during statement parsing. As a result, only one audit record is generated.

When an editioned object has a unified audit policy, it applies in all editions in which the object is visible.

When an editioned object is actualized, any unified audit policies that are attached to it are newly attached to the new actual occurrence. When you newly apply a unified audit policy to an inherited editioned object, this action will actualize it.

You can find the editions in which audited objects appear by querying the OBJECT_NAME and OBJ_EDITION_NAME columns in the UNIFIED_AUDIT_TRAIL data dictionary view.

You can create unified audit policies that capture the use of the READ ANY TABLE system privilege.

Based on the action that the user tried to perform and the privilege that was granted to the user, the SYSTEM_PRIVILEGE_USED column of the UNIFIED_AUDIT_TRAIL data dictionary view will record either the READ ANY TABLE system privilege or the SELECT ANY TABLE system privilege. For example, suppose the user has been granted the SELECT ANY TABLE privilege and then performs a query on a table. The audit trail will record that the user used the SELECT ANY TABLE system privilege. If the user was granted READ ANY TABLE and performed the same query, then the READ ANY TABLE privilege is recorded.

You can create unified audit policies that capture READ object privilege operations.

CREATE AUDIT POLICY read_hr_employees
 ACTIONS SELECT ON HR.EMPLOYEES;

The unified audit trail captures SELECT behavior based on whether a user has the READ ANY TABLE or the SELECT ANY TABLE privilege.

Table 22-3 describes how the unified audit trail captures these actions.

You can create a unified audit policy that uses a SYS_CONTEXT namespace-attribute pair to specify a condition.

For example, this audit condition can apply to a specific user who may fulfil the audit condition, or a computer host where the audit condition is fulfilled.

If the audit condition is satisfied, then Oracle Database creates an audit record for the event. As part of the condition definition, you must specify whether the audited condition is evaluated per statement occurrence, session, or database instance.

The WHEN clause in the CREATE AUDIT POLICY statement defines the condition in the audit policy.

CREATE AUDIT POLICY oe_orders_pol
 ACTIONS UPDATE ON OE.ORDERS
 WHEN 'SYS_CONTEXT(''USERENV'', ''IDENTIFICATION_TYPE'') = ''EXTERNAL'''
 EVALUATE PER STATEMENT;

The CREATE AUDIT POLICY statement can audit access to SQL*Plus.

Example 22-11 shows how to audit access to the database with SQL*Plus by users who have been directly granted the roles emp_admin and sales_admin.

CREATE AUDIT POLICY logon_pol
 ACTIONS LOGON
 WHEN 'INSTR(UPPER(SYS_CONTEXT(''USERENV'', ''CLIENT_PROGRAM_NAME'')), ''SQLPLUS'') > 0'
 EVALUATE PER SESSION;

AUDIT POLICY logon_pol BY USERS WITH GRANTED ROLES emp_admin, sales_admin;

The CREATE AUDIT POLICY statement can audit actions that are not in specific hosts.

Example 22-12 shows how to audit two actions (UPDATE and DELETE statements) on the OE.ORDERS table, but excludes the host names sales_24 and sales_12 from the audit. It performs the audit on a per session basis and writes audit records for failed attempts only.

CREATE AUDIT POLICY oe_table_audit1
 ACTIONS UPDATE ON OE.ORDERS, DELETE ON OE.ORDERS
 WHEN 'SYS_CONTEXT (''USERENV'', ''HOST'') NOT IN (''sales_24'',''sales_12'')'
 EVALUATE PER SESSION;

AUDIT POLICY oe_table_audit1 WHENEVER NOT SUCCESSFUL;

The CREATE AUDIT POLICY statement can audit both system-wide and schema-specific actions.

Example 22-13 shows a variation of Example 22-12 in which the UPDATE statement is audited system wide. The DELETE statement audit is still specific to the OE.ORDERS table.

CREATE AUDIT POLICY oe_table_audit2
 ACTIONS UPDATE, DELETE ON OE.ORDERS
 WHEN 'SYS_CONTEXT (''USERENV'', ''HOST'') NOT IN (''sales_24'',''sales_12'')'
 EVALUATE PER SESSION;

AUDIT POLICY oe_table_audit2;

The CREATE AUDIT POLICY statement can audit conditions.

Example 22-14 shows how to audit a condition based on each occurrence of the DELETE statement on the OE.ORDERS table and exclude user jmartin from the audit.

CREATE AUDIT POLICY sales_clerk_pol
 ACTIONS DELETE ON OE.ORDERS
 WHEN 'SYS_CONTEXT(''USERENV'', ''CLIENT_IDENTIFIER'') = ''sales_clerk'''
 EVALUATE PER STATEMENT;

AUDIT POLICY sales_clerk_pol EXCEPT jmartin;

The SYS_CONTEXT function can be used to find session IDs.

CONNECT SYS AS SYSDBA
Enter password: password

SELECT SYS_CONTEXT('USERENV', 'UNIFIED_AUDIT_SESSIONID') FROM DUAL;

SYS_CONTEXT('USERENV','UNIFIED_AUDIT_SESSIONID')
--------------------------------------------------------------------------------
2318470183

The SYS_CONTEXT function can find the session ID of a current non-administrative user session.

Example 22-16 shows how to find the unified audit session ID of a current user session for a non-administrative user.

CONNECT mblake -- Or, CONNECT mblake@hrpdb for a PDB
Enter password: password

SELECT SYS_CONTEXT('USERENV', 'UNIFIED_AUDIT_SESSIONID') FROM DUAL;

SYS_CONTEXT('USERENV','UNIFIED_AUDIT_SESSIONID')
--------------------------------------------------------------------------------
2776921346

The audit record conditions from a unified audit policy do not appear in the audit trail.

If the condition evaluates to true and the record is written, then the record appears in the audit trail. You can check the audit trail by querying the UNIFIED_AUDIT_TRAIL data dictionary view.

You can capture application context values in the unified audit trail.

This feature enables you to capture any application context values set by the database applications, while executing the audited statement.

If you plan to audit Oracle Label Security, then this feature captures session label activity for the database audit trail. The audit trail records all the values retrieved for the specified context-attribute value pairs.

The application context audit setting or the audit policy have session static semantics. In other words, if a new policy is enabled for a user, then the subsequent user sessions will see an effect of this command. After the session is established, then the policies and contexts settings are loaded and the subsequent AUDIT statements have no effect on that session.

For multitenant environments, the application context audit policy applies only to the current PDB.

The AUDIT statement with the CONTEXT keyword configures auditing for application context values.

AUDIT CONTEXT NAMESPACE clientcontext3 ATTRIBUTES module, action,
 CONTEXT NAMESPACE ols_session_labels ATTRIBUTES ols_pol1, ols_pol3
 BY appuser1, appuser2;

The NOAUDIT statement disables application context audit settings.

NOAUDIT CONTEXT NAMESPACE client_context ATTRIBUTES module,
 CONTEXT NAMESPACE ols_session_labels ATTRIBUTES ols_pol1, ols_pol3
 BY USERS WITH GRANTED ROLES emp_admin;

The AUDIT CONTEXT NAMESPACE statement can audit application context values.

Example 22-17 shows how to audit the clientcontext application values for the module and action attributes, by the user appuser1.

AUDIT CONTEXT NAMESPACE clientcontext ATTRIBUTES module, action
BY appuser1;

The AUDIT CONTEXT NAMESPACE statement can audit application context values from Oracle Label Security.

Example 22-18 shows how to audit an application context for Oracle Label Security called ols_session_labels, for the attributes ols_pol1 and ols_pol2.

AUDIT CONTEXT NAMESPACE ols_session_labels ATTRIBUTES ols_pol1, ols_pol2;

The UNIFIED_AUDIT_POLICIES data dictionary view lists application context audit events.

The APPLICATION_CONTEXTS column of the UNIFIED_AUDIT_TRAIL data dictionary view shows application context audit data. The application contexts appear as a list of semi-colon separated values.

For example:

SELECT APPLICATION_CONTEXTS FROM UNIFIED_AUDIT_TRAIL
 WHERE UNIFIED_AUDIT_POLICIES = 'app_audit_pol';

APPLICATION_CONTEXTS
----------------------------------------------------------
CLIENT_CONTEXT.APPROLE=MANAGER;E2E_CONTEXT.USERNAME=PSMITH

You must have the AUDIT_ADMIN role to audit Oracle Database Real Application Security events.

To access the audit trail, you can query the UNIFIED_AUDIT_TRAIL data dictionary view, whose Real Application Security-specific columns begin with XS_. If you want to find audit information about the internally generated VPD predicate that is created while an Oracle Real Application Security policy is being enabled, then you can query the RLS_INFO column.

Real Application Security-specific views are as follows:

• DBA_XS_AUDIT_TRAIL provides detailed information about Real Application Security events that were audited.

• DBA_XS_AUDIT_POLICY_OPTIONS describes the auditing options that were defined for Real Application Security unified audit policies.

• DBA_XS_ENB_AUDIT_POLICIES lists users for whom Real Application Security unified audit polices are enabled.

Oracle Database provides Real Application Security events that you can audit, such CREATE USER, UPDATE USER.

To find a list of auditable Real Application Security events that you can audit, you can query the COMPONENT and NAME columns of the AUDITABLE_SYSTEM_ACTIONS data dictionary view, as follows:

SELECT NAME FROM AUDITABLE_SYSTEM_ACTIONS WHERE COMPONENT = 'XS';

NAME
-------------
CREATE USER
UPDATE USER
DELETE USER
...

The unified audit trail can capture Oracle Database Real Application Security events for users, privileges, and roles.

The unified audit trail can capture Oracle Database Real Application Security security class and ACL audit events.

The unified audit trail can capture Oracle Database Real Application Security session audit events.

The unified audit trail can capture Oracle Database Real Application Security ALL events.

The CREATE AUDIT POLICY statement can create a unified audit policy for Oracle Real Application Security.

CREATE AUDIT POLICY audit_ras_pol
 ACTIONS COMPONENT=XS SWITCH USER, DISABLE ROLE;

The CREATE AUDIT POLICY statement can audit Real Application Security user account modifications.

Example 22-19 shows how to audit user bhurst's attempts to switch users and disable roles.

CREATE AUDIT POLICY ras_users_pol
 ACTIONS COMPONENT=XS SWITCH USER, DISABLE ROLE;

AUDIT POLICY ras_users_pol BY bhurst;

The CREATE AUDIT POLICY statement can set a condition for a Real Application Security unified audit policy.

Example 22-20 shows how to create Real Application Security unified audit policy that applies the audit only to actions from the nemosity computer host.

CREATE AUDIT POLICY ras_acl_pol
 ACTIONS DELETE ON OE.CUSTOMERS
 ACTIONS COMPONENT=XS CREATE ACL, UPDATE ACL, DELETE ACL
 WHEN 'SYS_CONTEXT(''USERENV'', ''HOST'') = ''nemosity'''
 EVALUATE PER INSTANCE;

AUDIT POLICY ras_acl_pol BY pfitch;

The DBA_XS_AUDIT_TRAIL data dictionary view lists Oracle Real Application Security audit events.

The following example queries the Real Application Security-specific view, DBA_XS_AUDIT_TRAIL:

SELECT XS_USER_NAME FROM DBA_XS_AUDIT_TRAIL
WHERE XS_ENABLED_ROLE = 'CLERK';

XS_USER_NAME
-------------
USER2

The UNIFIED_AUDIT_TRAIL data dictionary view automatically stores Oracle Recovery Manager audit events in the RMAN_column.

Unlike other Oracle Database components, you do not create a unified audit policy for Oracle Recovery Manager events.

However, you must have the AUDIT_ADMIN or AUDIT_VIEWER role in order to query the UNIFIED_AUDIT_TRAIL view to see these events. If you have the SYSBACKUP or the SYSDBA administrative privilege, then you can find additional information about Recovery Manager jobs by querying views such as V$RMAN_STATUS or V$RMAN_BACKUP_JOB_DETAILS.

The unified audit trail can capture Oracle Recovery Manager events.

Table 22-8 describes these events.

The UNIFIED_AUDIT_TRAIL data dictionary view lists Oracle Recovery Manager audit events.

Table 22-8 lists the columns in the UNIFIED_AUDIT_TRAIL data dictionary view that you can query to find Oracle Recovery Manager-specific audit data.

For example:

SELECT RMAN_OPERATION FROM UNIFIED_AUDIT_TRAIL
WHERE RMAN_OBJECT_TYPE = 'DB FULL';

RMAN_OPERATION
---------------
BACKUP

As with all unified auditing, you must have the AUDIT_ADMIN role before you can audit Oracle Database Vault events.

To create Oracle Database Vault unified audit policies, you must set the CREATE AUDIT POLICY statement's COMPONENT clause to DV, and then specify an action, such as Rule Set Failure, and an object, such as the name of a rule set.

To access the audit trail, you can query the following views:

• UNIFIED_AUDIT_TRAIL

• SYS.DV$CONFIGURATION_AUDIT

• SYS.DV$ENFORCEMENT_AUDIT

In the UNIFIED_AUDIT_TRAIL view, the Oracle Database Vault-specific columns begin with DV_. You must have the AUDIT_VIEWER role before you can query the UNIFIED_AUDIT_TRAIL view.

In addition to these views, the Database Vault reports capture the results of Database Vault-specific unified audit policies.

Audited Oracle Database Vault users include administrators and users whose activities affect Database Vault enforcement policies.

These users are as follows:

• Database Vault administrators. All configuration changes that are made to Oracle Database Vault are mandatorily audited. The auditing captures activities such as creating, modifying, or deleting realms, factors, command rules, rule sets, rules, and so on.The SYS.DV$CONFIGURATION_AUDIT data dictionary view captures configuration changes made by Database Vault administrators.

• Users whose activities affect Oracle Database Vault enforcement policies. The SYS.DV$ENFORCEMENT_AUDIT data dictionary view captures enforcement-related audits

The audit trail in an Oracle Database Vault environment captures all configuration changes or attempts at changes to Database Vault policies.

It also captures violations by users to existing Database Vault policies.

You can audit the following kinds of Oracle Database Vault events:

• All configuration changes or attempts at changes to Oracle Database Vault policies. It captures both Database Vault administrator changes and attempts made by unauthorized users.

• Violations by users to existing Database Vault policies. For example, if you create a policy to prevent users from accessing a specific schema table during non-work hours, the audit trail will capture this activity.

The unified audit trail captures Oracle Database Vault realm events.

Table 22-9 describes these events.

The unified audit trail can capture Oracle Database Vault rule set and rule audit events.

The unified audit trail can capture Oracle Database Vault command rule audit events.

The unified audit trail can capture Oracle Database Vault factor events.

The unified audit trail can capture Oracle Database Vault secure application role audit events.

The unified audit trail can capture Oracle Database Vault Oracle Label Security audit events.

The unified audit trail can capture Oracle Database Vault Oracle Data Pump audit events.

The unified audit trail can capture Oracle Database Vault enable and disable audit events.

The ACTIONS and ACTIONS COMPONENT clauses in the CREATE AUDIT POLICY statement can create unified audit policies for Oracle Database Vault events.

CREATE AUDIT POLICY audit_dv
 ACTIONS CREATE TABLE, SELECT
 ACTIONS COMPONENT=DV Realm Violation ON "Database Vault Account Management";

The CREATE AUDIT POLICY statement can audit Oracle Database Vault realms.

Example 22-21 shows how to audit a realm violation on the HR schema.

CREATE AUDIT POLICY dv_realm_hr
 ACTIONS SELECT, UPDATE, DELETE
 ACTIONS COMPONENT=DV Realm Violation ON "HR Schema Realm";

AUDIT POLICY dv_realm_hr EXCEPT psmith;

The CREATE AUDIT POLICY statement can audit Oracle Database Vault rule sets.

Example: Auditing an Oracle Database Vault Rule Set shows how to audit the Can Maintain Accounts/Profile rule set. The user dbv_acctmgr, who has the DV_ACCTMGR role and hence has privileges to manage user accounts and user profiles, is exempt from this audit policy.

CREATE AUDIT POLICY dv_rule_set_accts
 ACTIONS CREATE USER, ALTER USER, ALTER PROFILE
 ACTIONS COMPONENT=DV RULE SET FAILURE ON "Can Maintain Accounts/Profile";

AUDIT POLICY dv_rule_set_accts EXCEPT dbv_acctmgr;

The CREATE AUDIT POLICY statement can audit multiple Oracle Database Vault events.

Example 22-23 shows how to audit a realm violation and a rule set failure.

CREATE AUDIT POLICY audit_dv
 ACTIONS CREATE TABLE, SELECT
 ACTIONS COMPONENT=DV REALM VIOLATION ON "Oracle Enterprise Manager", Rule Set
 Failure ON "Allow Sessions";

AUDIT POLICY audit_dv EXCEPT psmith;

The CREATE AUDIT POLICY statement can audit Oracle Database Vault factors.

Example 22-24 shows how to audit two types of errors for one factor.

CREATE AUDIT POLICY audit_dv_factor
 ACTIONS COMPONENT=DV FACTOR ERROR ON "Database_Domain", Factor Validate Error ON "Client_IP";

AUDIT POLICY audit_dv_factor;

The UNIFIED_AUDIT_TRAIL data dictionary view lists Oracle Database Vault audited events.

The DV_* columns of the UNIFIED_AUDIT_TRAIL view show Oracle Database Vault-specific audit data.

For example:

SELECT DV_RULE_SET_NAME FROM UNIFIED_AUDIT_TRAIL
WHERE ACTION_NAME = 'UPDATE';

DV_RULE_SET_NAME
-----------------------
Allow System Parameters

As with all unified auditing, you must have the AUDIT_ADMIN role before you can audit Oracle Label Security (OLS) events.

To create Oracle Label Security unified audit policies, you must set the CREATE AUDIT POLICY statement COMPONENT clause to OLS.

To audit user session label information, you use the AUDIT statement to audit application context values.

To access the audit trail, you can query the UNIFIED_AUDIT_TRAIL data dictionary view. This view contains Oracle Label Security-specific columns whose names begin with OLS_. If you want to find audit information about the internally generated VPD predicate that is created when you apply an Oracle Label Security policy to a table, then you can query the RLS_INFO column.

The unified audit trail can capture Oracle Label Security audit events.

To find a list of auditable Oracle Label Security events that you can audit, you can query the COMPONENT and NAME columns of the AUDITABLE_SYSTEM_ACTIONS data dictionary view.

For example:

SELECT NAME FROM AUDITABLE_SYSTEM_ACTIONS WHERE COMPONENT = 'Label Security';

NAME
-------------
CREATE POLICY
ALTER POLICY
DROP POLICY
...

Table 22-17 describes the Oracle Label Security audit events.

The ORA_OLS_SESSION_LABELS application context can capture user session label usage for each Oracle Database event.

The attributes used by this application context refer to Oracle Label Security policies. .

The syntax is the same as the syntax used for application context auditing, described in Configuring Application Context Audit Settings. For example:

AUDIT CONTEXT NAMESPACE ORA_SESSION_LABELS ATTRIBUTES policy1, policy2;

Because the recording of session labels is not user-session specific, the BY user_list clause is not required for auditing Oracle Label Security application contexts.

To disable the auditing of user session label information, you use the NOAUDIT statement. For example, to stop auditing for policies policy1 and policy2, enter the following statement:

NOAUDIT CONTEXT NAMESPACE ORA_SESSION_LABELS ATTRIBUTES policy1, policy2;

The ACTIONS and ACTIONS COMPONENT clauses in the CREATE AUDIT POLICY statement can be used to create Oracle Label Security event audit policies.

CREATE AUDIT POLICY audit_ols
 ACTIONS SELECT ON OE.ORDERS
 ACTIONS COMPONENT=OLS ALL;

The AUDIT CONTEXT NAMESPACE statement can audit Oracle Label Security session label attributes.

Example 22-25 shows how to audit ORA_OLS_SESSION_LABELS application context attributes for the Oracle Label Security policies usr_pol1 and usr_pol2.

AUDIT CONTEXT NAMESPACE ORA_SESSION_LABELS ATTRIBUTES usr_pol1, usr_pol2;

The CREATE AUDIT POLICY statement can exclude users from policies.

CREATE AUDIT POLICY auth_ols_audit_pol
 ACTIONS SELECT ON HR.EMPLOYEES
 ACTIONS COMPONENT=OLS DROP POLICY, DISABLE POLICY;

AUDIT POLICY auth_ols_audit_pol EXCEPT ols_mgr;

The CREATE AUDIT POLICY statement can audit Oracle Label Security policy actions.

Example 22-27 shows how to audit the DROP POLICY, DISABLE POLICY, UNSUBSCRIBE OID events, and UPDATE and DELETE statements on the HR.EMPLOYEES table. Then this policy is applied to the HR and LBACSYS users, and audit records are written to the unified audit trail only when the audited actions are successful.

CREATE AUDIT POLICY generic_audit_pol
 ACTIONS UPDATE ON HR.EMPLOYEES, DELETE ON HR.EMPLOYEES
 ACTIONS COMPONENT=OLS DROP POLICY, DISABLE POLICY, UNSUBSCRIBE OID;

AUDIT POLICY generic_audit_pol BY HR, LBACSYS WHENEVER SUCCESSFUL;

The LBACSYS.ORA_GET_AUDITED_LABEL function can be used in a UNIFIED_AUDIT_TRAIL query to find audited Oracle Label Security session labels.

Example 22-28 shows how to use the LBACSYS.ORA_GET_AUDITED_LABEL function in a UNIFIED_AUDIT_TRAIL data dictionary view query.

SELECT ENTRY_ID, SESSIONID,
       LBACSYS.ORA_GET_AUDITED_LABEL( APPLICATION_CONTEXTS,'GENERIC_AUDIT_POL1') AS  SESSION_LABEL1,
       LBACSYS.ORA_GET_AUDITED_LABEL( APPLICATION_CONTEXTS,'GENERIC_AUDIT_POL2') AS  SESSION_LABEL2
FROM UNIFIED_AUDIT_TRAIL;
/

ENTRY_ID  SESSIONID  SESSION_LABEL1  SESSION_LABEL2
--------  ---------  --------------  --------------
       1       1023  SECRET          LEVEL_ALPHA
       2       1024  TOP_SECRET      LEVEL_BETA

The UNIFIED_AUDIT_TRAIL data dictionary view lists Oracle Label Security audit events.

The OLS_* columns of the UNIFIED_AUDIT_TRAIL view show Oracle Label Security-specific audit data. For example:

SELECT OLS_PRIVILEGES_USED FROM UNIFIED_AUDIT_TRAIL WHERE DBUSERNAME = 'psmith';

OLS_PRIVILEGES_USED
-------------------
READ
WRITEUP
WRITEACROSS

The session labels that the audit trail captures are stored in the APPLICATION_CONTEXTS column of the UNIFIED_AUDIT_TRAIL view. You can use the LBACSYS.ORA_GET_AUDITED_LABEL function to retrieve session labels that are stored in the APPLICATION_CONTEXTS column. This function accepts the UNIFIED_AUDIT_TRAIL.APPLICATION_CONTEXTS column value, and the Oracle Label Security policy name as arguments, and then returns the session label that is stored in the column for the specified policy.

You must have the AUDIT_ADMIN role to audit Oracle Data Mining events.

To access the audit trail, you can query the UNIFIED_AUDIT_TRAIL data dictionary view.

The unified audit trail can capture Oracle Data Mining audit events..

Table 22-18 describes these events.

The CREATE AUDIT POLICY statement ACTIONS and ON MINING MODEL clauses can be used to create Oracle Data Mining event unified audit policies.

CREATE AUDIT POLICY dm_ops ACTIONS RENAME ON MINING MODEL hr.dm_emp;

The CREATE AUDIT POLICY statement can audit multiple Oracle Data Mining operations.

Example 22-29 shows how to audit multiple Oracle Data Mining operations by user psmith. Include the ON MINING MODEL schema_name.model_name clause for each event, and separate each with a comma. This example specifies the same schema_name.model name for both actions, but the syntax enables you to specify different schema_name.model_name settings for different schemas and data models.

CREATE AUDIT POLICY dm_ops_pol
ACTIONS SELECT ON MINING MODEL dmuser1.nb_model, ALTER ON MINING MODEL dmuser1.nb_model;

AUDIT POLICY dm_ops_pol BY psmith;

The CREATE AUDIT POLICY statement can audit failed Oracle Data Mining operations by a user.

Example 22-30 shows how to audit all failed Oracle Data Mining operations by user psmith.

CREATE AUDIT POLICY dm_all_ops_pol ACTIONS ALL ON MINING MODEL dmuser1.nb_model;

AUDIT POLICY dm_all_ops_pol BY psmith WHENEVER NOT SUCCESSFUL;

The UNIFIED_AUDIT_TRAIL data dictionary view lists Oracle Data Mining audit events.

The following example shows how to query the UNIFIED_AUDIT_TRAIL data dictionary view for Data Mining audit events.

SELECT DBUSERNAME, ACTION_NAME, SYSTEM_PRIVILEGE_USED, RETURN_CODE,
OBJECT_SCHEMA, OBJECT_NAME, SQL_TEXT
FROM UNIFIED_AUDIT_TRAIL;

DBUSERNAME ACTION_NAME          SYSTEM_PRIVILEGE_USED     RETURN_CODE
---------- -------------------- ------------------------- -----------
OBJECT_SCHEMA        OBJECT_NAME
-------------------- --------------------
SQL_TEXT
--------------------------------------------------------------------------------
DMUSER1    CREATE MINING MODEL  CREATE MINING MODEL                 0
DMUSER1
BEGIN
  dbms_data_mining.create_model(model_name => 'nb_model',
                mining_function => dbms_data_mining.classification,
                data_table_name => 'dm_data',
                case_id_column_name => 'case_id',
                target_column_name => 'target');
END;

DMUSER1    SELECT MINING MODEL                                      0
DMUSER1              NB_MODEL
select prediction(nb_model using *) from dual

DMUSER2    SELECT MINING MODEL                                  40284
DMUSER1              NB_MODEL
select prediction(dmuser1.nb_model using *) from dual

DMUSER1    ALTER MINING MODEL                                       0
DMUSER1              NB_MODEL
BEGIN dbms_data_mining.rename_model('nb_model', 'nb_model1'); END;


DMUSER2    ALTER MINING MODEL                                   40284
DMUSER1              NB_MODEL
BEGIN dbms_data_mining.rename_model('dmuser1.nb_model1', 'nb_model'); END;


DMUSER2    ALTER MINING MODEL                                   40284
DMUSER1              NB_MODEL
BEGIN dbms_data_mining.rename_model('dmuser1.nb_model1', 'nb_model'); END;

The CREATE AUDIT POLICY statement COMPONENT clause must be set to DATAPUMP to create Oracle Data Pump unified audit policies.

You can audit Data Pump export (expdp) and import (impdp) operations.

As with all unified auditing, you must have the AUDIT_ADMIN role before you can audit Oracle Data Pump events.

To access the audit trail, query the UNIFIED_AUDIT_TRAIL data dictionary view. The Data Pump-specific columns in this view begin with DP_.

The unified audit trail can capture Oracle Data Pump events.

The unified audit trail captures information about both export (expdp) and import (impdp) operations.

The ACTIONS COMPONENT clause in the CREATE AUDIT POLICY statement can be used to create an Oracle Data Pump event unified audit policy.

CREATE AUDIT POLICY audit_dp_export_pol
 ACTIONS COMPONENT=DATAPUMP EXPORT;

The CREATE AUDIT POLICY statement can audit Oracle Data Pump import operations.

Example 22-31 shows how to audit all Oracle Data Pump import operations.

CREATE AUDIT POLICY audit_dp_import_pol
 ACTIONS COMPONENT=DATAPUMP IMPORT;

AUDIT POLICY audit_dp_import_pol;

The CREATE AUDIT POLICY statement can audit all Oracle Data Pump operations.

Example 22-32 shows how to audit both Oracle Database Pump export and import operations.

CREATE AUDIT POLICY audit_dp_all_pol
 ACTIONS COMPONENT=DATAPUMP ALL;

AUDIT POLICY audit_dp_all_pol BY SYSTEM;

The UNIFIED_AUDIT_TRAIL data dictionary view lists Oracle Data Pump audited events.

The DP_* columns of the UNIFIED_AUDIT_TRAIL view show Oracle Data Pump-specific audit data. For example:

SELECT DP_TEXT_PARAMETERS1, DP_BOOLEAN_PARAMETERS1 FROM UNIFIED_AUDIT_TRAIL
WHERE AUDIT_TYPE = 'DATAPUMP';

DP_TEXT_PARAMETERS1                            DP_BOOLEAN_PARAMETERS1
---------------------------------------------- ----------------------------------

MASTER TABLE:  "SCOTT"."SYS_EXPORT_TABLE_01",  MASTER_ONLY: FALSE,
JOB_TYPE: EXPORT,                              DATA_ONLY: FALSE,
METADATA_JOB_MODE: TABLE_EXPORT,               METADATA_ONLY: FALSE,
JOB VERSION: 12.1.0.0,                         DUMPFILE_PRESENT: TRUE,
ACCESS METHOD: DIRECT_PATH,                    JOB_RESTARTED: FALSE
DATA OPTIONS: 0,
DUMPER DIRECTORY: NULL
REMOTE LINK: NULL,
TABLE EXISTS: NULL,
PARTITION OPTIONS: NONE

(This output was reformatted for easier readability.)

You must have the AUDIT_ADMIN role to audit Oracle SQL*Loader direct path events.

To create SQL*Loader unified audit policies, you must set the CREATE AUDIT POLICY statement's COMPONENT clause to DIRECT_LOAD. You can audit direct path load operations only, not other SQL*Loader loads, such as conventional path loads.

To access the audit trail, you can query the DIRECT_PATH_NUM_COLUMNS_LOADED column in the UNIFIED_AUDIT_TRAIL data dictionary view.

The unified audit trail can capture SQL*Loader Direct Load Path events.

The unified audit trail captures information about direct path loads that SQL*Loader performs (that is, when you set direct=true on the SQL*Loader command line or in the SQL*Loader control file).

It also audits Oracle Call Interface (OCI) programs that use the direct path API.

The CREATE AUDIT POLICY statement ACTIONS COMPONENT clause can create unified audit policies for Oracle SQL*Loader direct path events.

CREATE AUDIT POLICY audit_sqlldr_pol
 ACTIONS COMPONENT=DIRECT_LOAD LOAD;

The CREATE AUDIT POLICY statement can audit Oracle SQL*Loader direct path load operations.

Example 22-31 shows how to audit SQL*Loader direct path load operations.

CREATE AUDIT POLICY audit_sqlldr_load_pol
 ACTIONS COMPONENT=DIRECT_LOAD LOAD;

AUDIT POLICY audit_sqlldr_load_pol;

The UNIFIED_AUDIT_TRAIL data dictionary view lists SQL*Loader direct path load audited events.

The DIRECT_PATH_NUM_COLUMNS_LOADED column of the UNIFIED_AUDIT_TRAIL view shows the number of columns that were loaded using the SQL*Loader direct path load method. For example:

SELECT DBUSERNAME, ACTION_NAME, OBJECT_SCHEMA, OBJECT_NAME, DIRECT_PATH_NUM_COLUMNS_LOADED FROM UNIFIED_AUDIT_TRAIL WHERE AUDIT_TYPE = 'DIRECT PATH API';

DBUSERNAME  ACTION_NAME OBJECT_SCHEMA OBJECT_NAME  DIRECT_PATH_NUM_COLUMNS_LOADED
----------- ----------- ------------- ------------ ------------------------------
RLAYTON     INSERT       HR            EMPLOYEES    4

An audit policy can be either a local audit policy, a CDB common audit policy, or an application common audit policy.

This applies to both unified audit policies and policies that are created using the AUDIT SQL statement.

• Local audit policy. This type of policy can exist in either the root (CDB or application) or the PDB (CDB or application). A local audit policy that exists in the root can contain object audit options for both local and common objects. Both local and common users who have been granted the AUDIT_ADMIN role can enable local policies: local users from their PDBs and common users from the root or the PDB to which they have privileges. You can enable a local audit policy for both local and common users and roles.

  You can create local audit policies for application local objects and application local roles, as well as system action options and system privilege options. You cannot enforce a local audit policy for a common user across all containers, nor can you enforce a common audit policy for a local user.

• CDB common audit policy. This type of policy is available to all PDBs in the multitenant environment. Only common users who have been granted the AUDIT_ADMIN role can create and maintain common audit policies. You can enable common audit policies only for common users. You must create common audit policies only in the root. This type of policy can contain object audit options of only common objects, and be enabled only for common users. You can enable a common audit policy for common users and roles only.

  You cannot enforce a common audit policy for a local user across all containers.

• Application common audit policy. Similar to CDB common audit policies, this type of policy is available to all PDBs in the multitenant environment. You can create common audit policies for application common objects and application common roles, as well as system action options and system privilege options. This type of policy can only be created in the application root container but can be enabled on both application common users and CDB common users. If you want to audit objects, ensure that these objects are application common objects. You can find if an object is an application common object by querying the SHARING column of the DBA_OBJECTS data dictionary view.

By default, audit policies are local to the current PDB, for both CDB and application scenarios.

Table 22-19 explains how audit policies apply in the different multitenant environments.

The CONTAINER clause is specific to multitenant environment use for the CREATE AUDIT POLICY statement.

CREATE AUDIT POLICY dict_updates
 ACTIONS UPDATE ON SYS.USER$,
  DELETE ON SYS.USER$,
  UPDATE ON SYS.LINK$,
  DELETE ON SYS.LINK$
  CONTAINER = ALL;

The CREATE AUDIT POLICY statement can create a local unified audit policy in either the root or a PDB.

When you create a local unified audit policy in the root, it only applies to the root and not across the multitenant environment.

Example 22-34 shows a local unified audit policy that has been created by the common user c##sec_admin from a PDB and applied to common user c##hr_admin.

CONNECT c##sec_admin@hrpdb
Enter password: password
Connected.

CREATE AUDIT POLICY table_privs
 PRIVILEGES CREATE ANY TABLE, DROP ANY TABLE
 CONTAINER = CURRENT;

AUDIT POLICY table_privs BY c##hr_admin;

The CREATE AUDIT POLICY statement can create a CDB common unified audit policy.

Example 22-35 shows a common unified audit policy that has been created by the common user c##sec_admin from the root and applied to common user c##hr_admin.

CONNECT c##sec_admin
Enter password: password
Connected.

CREATE AUDIT POLICY admin_pol
 ACTIONS CREATE TABLE, ALTER TABLE, DROP TABLE
 ROLES c##hr_mgr, c##hr_sup
 CONTAINER = ALL;

AUDIT POLICY admin_pol BY c##hr_admin;

You can query unified audit policy views from either the root or the PDB in which the action occurred.

You can perform the following types of queries:

• Audit records from all PDBs. The audit trail reflects audited actions that have been performed in the PDBs. For example, if user lbrown in PDB1 performs an action that has been audited by either a common or a local audit policy, then the audit trail will capture this action. The DBID column in the UNIFIED_AUDIT_TRAIL data dictionary view indicates the PDB in which the audited action takes place and to which the policy applies. If you want to see audit records from all PDBs, you should query the CDB_UNIFIED_AUDIT_TRAIL data dictionary view from the root.

• Audit records from common audit policies. This location is where the common audit policy results in an audit record. The audit record can be generated anywhere in the multitenant environment—the root or the PDBs, depending on where the action really occurred. For example, the common audit policy fga_pol audits the EXECUTE privilege on the DBMS_FGA PL/SQL package, and if this action occurs in PDB1, then the audit record is generated in PDB1 and not in the root. Hence, the audit record can be seen in PDB1.

  You can query the UNIFIED_AUDIT_TRAIL data dictionary view for the policy from either the root or a PDB if you include a WHERE clause for the policy name (for example, WHERE UNIFIED_AUDIT_POLICIES = 'FGA_POL').

The following example shows how to find the results of a common unified audit policy:

CONNECT c##sec_admin
Enter password: password
Connected.

SELECT DBID, ACTION_NAME, OBJECT_SCHEMA, OBJECT_NAME FROM CDB_UNIFIED_AUDIT_TRAIL WHERE DBUSERNAME = 'c##hr_admin';
46892-1
DBID        ACTION_NAME  OBJECT_SCHEMA  OBJECT_NAME
----------- -----------  -------------  -----------
653916017   UPDATE       HR             EMPLOYEES
653916018   UPDATE       HR             JOB_HISTORY
653916017   UPDATE       HR             JOBS

You can change most properties in a unified audit policy, except for its CONTAINER setting.

You cannot alter unified audit policies in a multitenant environment. For example, you cannot turn a common unified audit policy into a local unified audit policy.

To find existing unified audit policies, query the AUDIT_UNIFIED_POLICIES data dictionary view. If you want to find only the enabled unified audit policies, then query the AUDIT_UNIFIED_ENABLED_POLICIES view. You can alter both enabled and disabled audit policies. If you alter an enabled audit policy, it remains enabled after you alter it.

After you alter an object unified audit policy, the new audit settings take place immediately, for both the active and subsequent user sessions. If you alter system audit options, or audit conditions of the policy, then they are activated for new user sessions, but not the current user session.

The ALTER AUDIT POLICY statement can modify a unified audit policy.

The ALTER AUDIT POLICY statement can alter conditions in unified audit policies.

Example 22-37 shows how to change a condition in an existing unified audit policy.

ALTER AUDIT POLICY orders_unified_audpol
 ADD ACTIONS INSERT ON SCOTT.EMP
CONDITION 'SYS_CONTEXT(''ENTERPRISE'', ''GROUP'') =  ''ACCESS_MANAGER'''
EVALUATE PER SESSION;

The ALTER AUDIT POLICY statement can alter Oracle Label Security components in an audit policy.

Example 22-38 shows how to alter an Oracle Label Security component in an audit policy.

ALTER AUDIT POLICY audit_ols
 ADD ACTIONS SELECT ON HR.EMPLOYEES
 ACTIONS COMPONENT=OLS DROP POLICY, DISABLE POLICY, REMOVE POLICY;

The ALTER AUDIT POLICY statement can alter roles in a unified audit policy.

Example 22-39 shows how to add roles to a common unified audit policy.

CONNECT c##sec_admin
Enter password: password
Connected.

ALTER AUDIT POLICY RoleConnectAudit
 ADD ROLES c##role1, c##role2;

The ALTER AUDIT POLICY statement can drop a condition from a unified audit policy.

Example 22-40 shows how to drop a condition from an existing unified audit policy.

ALTER AUDIT POLICY orders_unified_audpol
CONDITION DROP;

The AUDIT statement with the POLICY clause enables a unified audit policy, applying for all types of audit options, including object-level options.

The policy does not take effect until after the audited users (or users who have been granted the roles associated with the policy) log into the database instance. In other words, if you create and enable a policy while the audited users are logged in, then the policy cannot collect audit data; the users must log out and then log in again before auditing can begin. Once the session is set up with auditing for it, then the setting lasts as long as the user session and then ends when the session ends.

You can enable the audit policy for individual users or for roles. Enabling the audit policy for roles allows you to enable the policy for a group of users who have been directly granted the role. When the role has been directly granted to a new user, then the policy automatically applies to the user. When the role is revoked from a user, then the policy no longer applies to the user.

You can check the results of the audit by querying the UNIFIED_AUDIT_TRAIL data dictionary view. To find a list of existing unified audit policies, query the AUDIT_UNIFIED_POLICIES data dictionary view.

The AUDIT statement lets you specify the following optional additional settings:

• Whether to apply the unified audit policy to one or more users or roles.To apply the policy to one or more users or roles, including administrative users who log in with the SYSDBA administrative privilege (such as SYS), use the BY clause. For example, to apply the policy to users SYS and SYSTEM:

  For example, to apply the policy to two users:

  AUDIT POLICY role_connect_audit_pol BY SYS, SYSTEM;


  To apply a policy to users who have been directly granted the DBA and CDB_DBA roles:

  AUDIT POLICY admin_audit_pol BY USERS WITH GRANTED ROLES DBA, CDB_DBA;


• Whether to exclude users from the unified audit policy. To exclude users from the audit policy, include the EXCEPT clause.

  For example:

  AUDIT POLICY role_connect_audit_pol EXCEPT rlee, jrandolph;


• Whether to create an audit record if the activity succeeds or fails. This method of auditing reduces the audit trail, helping you to focus on specific actions. This can aid in maintaining good database performance. Enter one of the following clauses:

  • WHENEVER SUCCESSFUL audits only successful executions of the user’s activity.

  • WHENEVER NOT SUCCESSFUL audits only failed executions of the user’s activity. Monitoring unsuccessful SQL statement can expose users who are snooping or acting maliciously, though most unsuccessful SQL statements are neither.

  For example:

  AUDIT POLICY role_connect_audit_pol WHENEVER NOT SUCCESSFUL;


  If you omit this clause, then both failed and successful user activities are written to the audit trail.

Note the following:

• The unified audit policy only can have either the BY, BY USERS WITH GRANTED ROLES, or the EXCEPT clause, but not more than one of these clauses for the same policy.

• If you run multiple AUDIT statements on the same unified audit policy but specify different BY users or different BY USERS WITH GRANTED ROLES roles, then Oracle Database audits all of these users or roles.

• If you run multiple AUDIT statements on the same unified audit policy but specify different EXCEPT users, then Oracle Database uses the last exception user list, not any of the users from the preceding lists. This means the effect of the earlier AUDIT POLICY ... EXCEPT statements are overridden by the latest AUDIT POLICY ... EXCEPT statement.

• You cannot use the EXCEPT clause for roles. It applies to users only.

• You can only enable common unified audit policies for common users or roles.

• In a multitenant environment, you can enable a common audit policy only from the root and a local audit policy only from the PDB to which it applies.

The AUDIT POLICY statement can enable a unified audit policy.

The AUDIT POLICY statement can enable a unified audit policy using conditions, such as WHENEVER NOT SUCCESSFUL.

Example 22-41 shows how to enable a unified audit policy to record only failed actions by the user dv_admin.

AUDIT POLICY dv_admin_pol BY tjones
 WHENEVER NOT SUCCESSFUL;

The NOAUDIT statement with the POLICY clause can disable a unified audit policy.

In the NOAUDIT statement, you can specify a BY user or BY USERS WITH GRANTED ROLES role list, but not an EXCEPT user list. The disablement of a unified audit policy takes effect on subsequent user sessions.

You can find a list of existing unified audit policies by querying the AUDIT_UNIFIED_POLICIES data dictionary view.

In a multitenant environment, you can disable a common audit policy only from the root and a local audit policy only from the PDB to which it applies.

The NOAUDIT statement can disable a unified audit policy using supported audit options.

NOAUDIT POLICY logons_pol;

The NOAUDIT POLICY statement disable a unified audit policy using filtering, such as by user name.

Example 22-42 shows examples of how to disable a unified audit policy for a user and for a role.

NOAUDIT POLICY dv_admin_pol BY tjones;

NOAUDIT POLICY dv_admin_pol BY USERS WITH GRANTED ROLES emp_admin;

The DROP AUDIT POLICY statement can be used to unified audit policies.

If a unified audit policy is already enabled for a session, the effect of dropping the policy is not seen by this existing session. Until that time, the unified audit policy's settings remain in effect. For object-related unified audit policies, however, the effect is immediate.

You can find a list of existing unified audit policies by querying the AUDIT_UNIFIED_POLICIES data dictionary view.

When you disable an audit policy before dropping it, ensure that you disable it using the same settings that you used to enable it. For example, suppose you enabled the logon_pol policy as follows:

AUDIT POLICY logon_pol BY HR, OE;

Before you can drop it, your NOAUDIT statement must include the HR and OE users as follows:

NOAUDIT POLICY logon_pol BY HR, OE;

In a multitenant environment, you can drop a common audit policy only from the root and a local audit policy only from the PDB to which it applies.

To drop a unified audit policy, you must first disable it, and then run the DROP AUDIT POLICY statement to remove it.

The NOAUDIT POLICY and DROP AUDIT POLICY statements can disable and drop a unified audit policy.

Example 22-43 shows how to disable and drop a common unified audit policy.

CONNECT c##sec_admin
Enter password: password
Connected.

NOAUDIT POLICY dv_admin_pol;

DROP AUDIT POLICY dv_admin_pol

You must first create users and ensure that the user OE is active.

1. Log on as user SYS with the SYSDBA administrative privilege.

   sqlplus sys as sysdba
   Enter password: password


2. In a multitenant environment, connect to the appropriate PDB.

   For example:

   CONNECT SYS@hrpdb AS SYSDBA
   Enter password: password


   To find the available PDBs, query the DBA_PDBS data dictionary view. To check the current PDB, run the show con_name command.

3. Create the local user policy_admin, who will create the fine-grained audit policy.

   CREATE USER policy_admin IDENTIFIED BY password;
   GRANT CREATE SESSION, AUDIT_ADMIN TO policy_admin;


   Follow the guidelines in Minimum Requirements for Passwords to replace password with a password that is secure.

4. Create the local user account auditor, who will check the audit trail for this policy.

   CREATE USER policy_auditor IDENTIFIED BY password;
   GRANT CREATE SESSION, AUDIT_VIEWER TO policy_auditor;


5. The sample user OE will also be used in this tutorial, so query the DBA_USERS data dictionary view to ensure that OE is not locked or expired.

   SELECT USERNAME, ACCOUNT_STATUS FROM DBA_USERS WHERE USERNAME = 'OE';


   The account status should be OPEN. If the DBA_USERS view lists user OE as locked and expired, log in as user SYSTEM and then enter the following statement to unlock the OE account and create a new password:

   ALTER USER OE ACCOUNT UNLOCK IDENTIFIED BY password;


   Follow the guidelines in Minimum Requirements for Passwords to replace password with a password that is secure. For greater security, do not give the OE account the same password from previous releases of Oracle Database.

Next, you are ready to create the unified audit policy.

1. Connect to SQL*Plus as user policy_admin.

   CONNECT policy_admin -- Or, CONNECT policy_admin@hrpdb
   Enter password: password


2. Create the following policy:

   CREATE AUDIT POLICY orders_unified_audpol
     ACTIONS INSERT ON OE.ORDERS, UPDATE ON OE.ORDERS, DELETE ON OE.ORDERS, SELECT ON OE.ORDERS
     WHEN 'SYS_CONTEXT(''USERENV'', ''CLIENT_IDENTIFIER'') = ''robert'''
       EVALUATE PER STATEMENT;

   AUDIT POLICY orders_unified_audpol;


   In this example, the AUDIT_CONDITION parameter assumes that the nondatabase user is named robert. The policy will monitor any INSERT, UPDATE, DELETE, and SELECT statements that robert will attempt. Remember that the user's CLIENT_IDENTITIFER setting that you enter in the policy is case sensitive and that the policy only recognizes the case used for the identity that you specify here. In other words, later on, if the user session is set to Robert or ROBERT, the policy's condition will not be satisfied.

To test the policy, use OE must try to select from the OE.ORDERS table.

1. Connect as user OE and select from the OE.ORDERS table.

   CONNECT OE -- Or, CONNECT OE@hrpdb
   Enter password: password

   SELECT COUNT(*) FROM ORDERS;


   The following output appears:

     COUNT(*)
   ----------
          105


2. Connect as user policy_auditor and then check if any audit records were generated.

   CONNECT policy_auditor -- Or, CONNECT policy_auditor@hrpdb
   Enter password: password

   col dbusername format a10
   col client_identifier format a20
   col sql_text format a29

   SELECT DBUSERNAME, CLIENT_IDENTIFIER, SQL_TEXT FROM UNIFIED_AUDIT_TRAIL
    WHERE SQL_TEXT LIKE '%FROM ORDERS%';


   The following output appears:

   no rows selected


3. Reconnect as user OE, set the client identifier to robert, and then reselect from the OE.ORDERS table.

   CONNECT OE -- Or, CONNECT OE@hrpdb
   Enter password: password

   EXEC DBMS_SESSION.SET_IDENTIFIER('robert');

   SELECT COUNT(*) FROM ORDERS;


   The following output should appear:

     COUNT(*)
   ----------
          105


4. Reconnect as user auditor and then check the audit trail again.

   CONNECT policy_auditor -- Or, CONNECT policy_auditor@hrpdb
   Enter password: password

   SELECT DBUSERNAME, CLIENT_IDENTIFIER, SQL_TEXT FROM UNIFIED_AUDIT_TRAIL
    WHERE SQL_TEXT LIKE '%FROM ORDERS%';


   This time, because robert has made his appearance and queried the OE.ORDERS table, the audit trail captures his actions:

   DBUSERNAME CLIENT_IDENTIFIER SQL_TEXT
   ---------- ----------------- ----------------------------
   OE         robert            SELECT COUNT(*) FROM ORDERS;


If you no longer need the components of this tutorial, then you can remove them.

1. Connect to SQL*Plus as user policy_admin, and then manually disable and drop the orders_unified_audpol policy.

   CONNECT policy_admin -- Or, CONNECT policy_admin@hrpdb
   Enter password: password

   NOAUDIT POLICY orders_unified_audpol;
   DROP AUDIT policy orders_unified_audpol;


   (Unified audit policies reside in the SYS schema, not the schema of the user who created them.)

2. Connect to SQL*Plus as user SYSTEM.

   CONNECT SYSTEM -- Or, CONNECT SYSTEM@hrpdb
   Enter password: password


3. Drop users policy_admin and policy_auditor.

   DROP USER policy_admin;
   DROP USER policy_auditor;


4. If you want, lock and expire OE, unless other users want to use this account:

   ALTER USER OE PASSWORD EXPIRE ACCOUNT LOCK;


The ORA_RAS_POLICY_MGMT predefined unified audit policy audits policies for all Oracle Real Application Security administrative actions on application users, roles, and policies.

The following CREATE AUDIT POLICY statement describes the ORA_RAS_POLICY_MGMT audit policy. By default, this policy is not enabled.

CREATE AUDIT POLICY ORA_RAS_POLICY_MGMT
 ACTIONS COMPONENT=XS
  CREATE USER, UPDATE USER, DELETE USER,
  CREATE ROLE, UPDATE ROLE, DELETE ROLE, GRANT ROLE, REVOKE ROLE,
  ADD PROXY, REMOVE PROXY,
  SET USER PASSWORD, SET USER VERIFIER, SET USER PROFILE,
  CREATE ROLESET, UPDATE ROLESET, DELETE ROLESET,
  CREATE SECURITY CLASS, UPDATE SECURITY CLASS, DELETE SECURITY CLASS,
  CREATE NAMESPACE TEMPLATE, UPDATE NAMESPACE TEMPLATE, DELETE NAMESPACE TEMPLATE,
  CREATE ACL, UPDATE ACL, DELETE ACL,
  CREATE DATA SECURITY, UPDATE DATA SECURITY, DELETE DATA SECURITY,
  ENABLE DATA SECURITY, DISABLE DATA SECURITY,
  ADD GLOBAL CALLBACK, DELETE GLOBAL CALLBACK, ENABLE GLOBAL CALLBACK;

The ORA_RAS_SESSION_MGMT predefined unified audit policy audits policies for all run-time Oracle Real Application Security session actions and namespace actions.

The following CREATE AUDIT POLICY statement describes the ORA_RAS_SESSION_MGMT policy. By default, this policy is not enabled.

CREATE AUDIT POLICY ORA_RAS_SESSION_MGMT
 ACTIONS COMPONENT=XS
  CREATE SESSION, DESTROY SESSION,
  ENABLE ROLE, DISABLE ROLE,
  SET COOKIE, SET INACTIVE TIMEOUT,
  SWITCH USER, ASSIGN USER,
  CREATE SESSION NAMESPACE, DELETE SESSION NAMESPACE,
  CREATE NAMESPACE ATTRIBUTE, GET NAMESPACE ATTRIBUTE, SET NAMESPACE ATTRIBUTE,
  DELETE NAMESPACE ATTRIBUTE;

The DBMS_FGA PL/SQL package can be used to combine statements into one policy and perform other fine-grained auditing management tasks.

However, unless you want to perform column-level auditing or use event handlers with your audit policy, you should create audit policies as described in Auditing Activities with Unified Audit Policies and the AUDIT Statement.

The DBMS_FGA PL/SQL package enables you to add all combinations of SELECT, INSERT, UPDATE, and DELETE statements to one policy. You also can audit MERGE statements, by auditing the underlying actions of INSERT and UPDATE. To audit MERGE statements, configure fine-grained access on the INSERT and UPDATE statements. Only one record is generated for each policy for successful MERGE operations.

To administer fine-grained audit policies, you must have be granted the AUDIT_ADMIN role. Note also that the EXECUTE privilege for the DBMS_FGA package is mandatorily audited.

The audit policy is bound to the table for which you created it. This simplifies the management of audit policies because the policy only needs to be changed once in the database, not in each application. In addition, no matter how a user connects to the database—from an application, a Web interface, or through SQL*Plus or Oracle SQL Developer—Oracle Database records any actions that affect the policy.

If any rows returned from a query match the audit condition that you define, then Oracle Database inserts an audit entry into the fine-grained audit trail. This entry excludes all the information that is reported in the regular audit trail. In other words, only one row of audit information is inserted into the audit trail for every fine-grained audit policy that evaluates to true.

You can create DBMS_FGA policies for use in an editions environment.

If you plan to use the DBMS_FGA package policy across different editions, then you can control the results of the policy: whether the results are uniform across all editions, or specific to the edition in which the policy is used.

In a multitenant environment, the DBMS_FGA PL/SQL package applies only to the current local PDBs.

You cannot create one policy for the entire multitenant environment. The policy must be specific to objects within a PDB. To find PDBs, you can query the DBA_PDBS data dictionary view.

The DBMS_FGA.ADD_POLICY procedure creates a fine-grained audit policy.

• About Creating a Fine-Grained Audit Policy
  The DBMS_FGA.ADD_POLICY procedure creates an audit policy using the supplied predicate as the audit condition.
• Syntax for Creating a Fine-Grained Audit Policy
  The DBMS_FGA.ADD_POLICY procedure includes many settings, such as the ability to use a handler for complex auditing.
• Audits of Specific Columns and Rows
  You can fine-tune audit behavior by targeting a specific column (relevant column) to be audited if a condition is met.

The DBMS_FGA.ADD_POLICY procedure can create a fine-grained audit policy using multiple statement types.

Example 22-44 shows how to audit statements INSERT, UPDATE, DELETE, and SELECT on table HR.EMPLOYEES.

Note that this example omits the audit_column_opts parameter, because it is not a mandatory parameter.

BEGIN
  DBMS_FGA.ADD_POLICY(
   object_schema      => 'HR',
   object_name        => 'EMPLOYEES',
   policy_name        => 'chk_hr_employees',
   audit_column       => 'SALARY',
   enable             =>  TRUE,
   statement_types    => 'INSERT, UPDATE, SELECT, DELETE');
END;
/

SELECT POLICY_NAME FROM DBA_AUDIT_POLICIES;

POLICY_NAME
-------------------------------
CHK_HR_EMPLOYEES

SELECT COUNT(*) FROM HR.EMPLOYEES WHERE COMMISSION_PCT = 20 AND SALARY > 4500;

SELECT SALARY FROM HR.EMPLOYEES WHERE DEPARTMENT_ID = 50;

DELETE FROM HR.EMPLOYEES WHERE SALARY > 1000000;

The DBMS_FGA.DISABLE_POLICY procedure disables a fine-grained audit policy.

BEGIN
 DBMS_FGA.DISABLE_POLICY(
  object_schema        => 'HR',
  object_name          => 'EMPLOYEES',
  policy_name          => 'chk_hr_employees');
END;
/

The DBMS_FGA.ENABLE_POLICY procedure enables a fine-grained audit policy.

BEGIN
 DBMS_FGA.ENABLE_POLICY(
  object_schema        => 'HR',
  object_name          => 'EMPLOYEES',
  policy_name          => 'chk_hr_employees',
  enable               => TRUE);
END;
/

The DBMS_FGA.DROP_POLICY procedure drops a fine-grained audit policy.

BEGIN
 DBMS_FGA.DROP_POLICY(
  object_schema      => 'HR',
  object_name        => 'EMPLOYEES',
  policy_name        => 'chk_hr_employees');
END;
/

This tutorial shows how you can add an email alert to a fine-grained audit policy that goes into effect when a user (or an intruder) violates the policy.

To add an email alert to a fine-grained audit policy, you first must create a procedure that generates the alert, and then use the following DBMS_FGA.ADD_POLICY parameters to call this function when someone violates this policy:

• handler_schema: The schema in which the handler event is stored

• handler_module: The name of the event handler

The alert can come in any form that best suits your environment: an email or pager notification, updates to a particular file or table, and so on. Creating alerts also helps to meet certain compliance regulations, such as California Senate Bill 1386. In this tutorial, you will create an email alert.

In this tutorial, you create an email alert that notifies a security administrator that a Human Resources representative is trying to select or modify salary information in the HR.EMPLOYEES table. The representative is permitted to make changes to this table, but to meet compliance regulations, we want to create a record of all salary selections and modifications to the table.

The UTL_MAIL PL/SQL manages email that includes commonly used email features, such as attachments, CC, and BCC.

1. Log on as user SYS with the SYSDBA administrative privilege.

   sqlplus sys as sysdba
   Enter password: password


2. In a multitenant environment, connect to the appropriate PDB.

   For example:

   CONNECT SYS@hrpdb AS SYSDBA
   Enter password: password


   To find the available PDBs, query the DBA_PDBS data dictionary view. To check the current PDB, run the show con_name command.

3. Install the UTL_MAIL package.

   @$ORACLE_HOME/rdbms/admin/utlmail.sql
   @$ORACLE_HOME/rdbms/admin/prvtmail.plb


   The UTL_MAIL package enables you to manage email.

   Be aware that currently, the UTL_MAIL PL/SQL package does not support SSL servers.

4. Check the current value of the SMTP_OUT_SERVER initialization parameter, and make a note of this value so that you can restore it when you complete this tutorial.

   For example:

   SHOW PARAMETER SMTP_OUT_SERVER


   If the SMTP_OUT_SERVER parameter has already been set, then output similar to the following appears:

   NAME                    TYPE              VALUE
   ----------------------- ----------------- ----------------------------------
   SMTP_OUT_SERVER         string            some_imap_server.example.com


5. Issue the following ALTER SYSTEM statement:

   ALTER SYSTEM SET SMTP_OUT_SERVER="imap_mail_server.example.com";


   Replace imap_mail_server.example.com with the name of your SMTP server, which you can find in the account settings in your email tool. Enclose these settings in quotation marks. For example:

   ALTER SYSTEM SET SMTP_OUT_SERVER="my_imap_server.example.com";



6. Connect as SYS using the SYSOPER privilege and then restart the database.

   CONNECT SYS AS SYSOPER -- Or, CONNECT SYS@hrpdb AS SYSOPER
   Enter password: password

   SHUTDOWN IMMEDIATE
   STARTUP


7. Ensure that the SMTP_OUT_SERVER parameter setting is correct.

   CONNECT SYS AS SYSDBA -- Or, CONNECT SYS@hrpdb AS SYSDBA
   Enter password: password

   SHOW PARAMETER SMTP_OUT_SERVER


   Output similar to the following appears:

   NAME                    TYPE              VALUE
   ----------------------- ----------------- ----------------------------------
   SMTP_OUT_SERVER         string            my_imap_server.example.com


You must create an administrative account and an auditor user.

1. Ensure that you are connected as SYS using the SYSDBA administrative privilege, and then create the fga_admin user, who will create the fine-grained audit policy.

   For example:

   CONNECT SYS AS SYSDBA -- Or, CONNECT SYS@hrpdb AS SYSDBA
   Enter password: password

   CREATE USER fga_admin IDENTIFIED BY password;
   GRANT CREATE SESSION, CREATE PROCEDURE, AUDIT_ADMIN TO fga_admin;
   GRANT EXECUTE ON UTL_TCP TO fga_admin;
   GRANT EXECUTE ON UTL_SMTP TO fga_admin;
   GRANT EXECUTE ON UTL_MAIL TO fga_admin;
   GRANT EXECUTE ON DBMS_NETWORK_ACL_ADMIN TO fga_admin;


   Follow the guidelines in Minimum Requirements for Passwordsto replace password with a password that is secure.

   The UTL_TCP, UTL_SMTP, UTL_MAIL, and DBMS_NETWORK_ACL_ADMIN PL/SQL packages are used by the email security alert that you create.

2. Create the auditor user, who will check the audit trail for this policy.

   GRANT CREATE SESSION TO fga_auditor IDENTIFIED BY password;
   GRANT AUDIT_VIEWER TO fga_auditor;


3. Connect as user SYSTEM.

   CONNECT SYSTEM -- Or, CONNECT SYSTEM@hrpdb
   Enter password: password


4. Ensure that the HR schema account is unlocked and has a password. If necessary, unlock HR and grant this user a password.

   SELECT USERNAME, ACCOUNT_STATUS FROM DBA_USERS WHERE USERNAME = 'HR';


   The account status should be OPEN. If the DBA_USERS view lists user HR as locked and expired, then enter the following statement to unlock the HR account and create a new password:

   ALTER USER HR ACCOUNT UNLOCK IDENTIFIED BY password;


   Follow the guidelines in Minimum Requirements for Passwords to create a password that is secure. For greater security, do not give the HR account the same password from previous releases of Oracle Database.

5. Create a user account for Susan Mavris, who is an HR representative whose actions you will audit, and then grant this user access to the HR.EMPLOYEES table.

   GRANT CREATE SESSION TO smavris IDENTIFIED BY password;
   GRANT SELECT, INSERT, UPDATE, DELETE ON HR.EMPLOYEES TO SMAVRIS;


An access control list (ACL) file can be used to enable fine-grained access to external network services.

1. Connect to SQL*Plus as user fga_admin.

   CONNECT fga_admin -- Or, CONNECT fga_admin@hrpdb
   Enter password: password


2. Configure the following access control setting and its privilege definitions.

   BEGIN
    DBMS_NETWORK_ACL_ADMIN.APPEND_HOST_ACE(
     host       => 'SMTP_OUT_SERVER_setting',
     lower_port => 25,
     ace        =>  xs$ace_type(privilege_list => xs$name_list('smtp'),
                                principal_name => 'FGA_ADMIN',
                                principal_type => xs_acl.ptype_db));
   END;
   /



   In this example:

   • SMTP_OUT_SERVER_setting: Enter the SMTP_OUT_SERVER setting that you set for the SMTP_OUT_SERVER parameter in Step 1: Install and Configure the UTL_MAIL PL/SQL Package. This setting should match exactly the setting that your email tool specifies for its outgoing server.

   • lower_port: Enter the port number that your email tool specifies for its outgoing server. Typically, this setting is 25. Enter this value for the lower_port setting. (Currently, the UTL_MAIL package does not support SSL. If your email server is an SSL server, then enter 25 for the port number, even if the email server uses a different port number.)

   • ace: Define the privileges here.

The email security alert PL/SQL procedure generates a message describing the violation and then sends this message to the appropriate users.

The fine-grained audit policy will trigger the alert when the policy is violated.

1. As user fga_admin, create the chk_hr_emp policy fine-grained audit policy as follows.

   BEGIN
    DBMS_FGA.ADD_POLICY (
     object_schema      =>  'HR',
     object_name        =>  'EMPLOYEES',
     policy_name        =>  'CHK_HR_EMP',
     audit_column       =>  'SALARY',
     handler_schema     =>  'FGA_ADMIN',
     handler_module     =>  'EMAIL_ALERT',
     enable             =>   TRUE,
     statement_types    =>  'SELECT, UPDATE');
   END;
   /


2. Commit the changes you have made to the database.

   COMMIT;


3. Test the settings that you have created so far.

   EXEC email_alert ('hr', 'employees', 'chk_hr_emp');


   SQL*Plus should display a PL/SQL procedure successfully completed message, and in a moment, depending on the speed of your email server, you should receive the email alert.

   If you receive an ORA-24247: network access denied by access control list (ACL) error followed by ORA-06512: at stringline string errors, then check the settings in the access control list file.

With the components in place, you are ready to test the alert.

1. Connect to SQL*Plus as user smavris, check your salary, and give yourself a nice raise.

   CONNECT smavris -- Or, CONNECT smavris@hrpdb
   Enter password: password

   SELECT SALARY FROM HR.EMPLOYEES WHERE LAST_NAME = 'Mavris';

   SALARY
   -----------
   6500

   UPDATE HR.EMPLOYEES SET SALARY = 38000 WHERE LAST_NAME = 'Mavris';


   By now, depending on the speed of your email server, you (or your recipient) should have received an email with the subject header Table modification on HR.EMPLOYEES notifying you of the tampering of the HR.EMPLOYEES table. Now all you need to do is to query the UNIFIED_AUDIT_TRAIL data dictionary view to find who the violator is.

2. As user fga_auditor, query the UNIFIED_AUDIT_TRAIL data dictionary view as follows:

   CONNECT fga_auditor -- Or, CONNECT fga_auditor@hrpdb
   Enter password: password

   col dbusername format a20
   col sql_text format a66
   col audit_type format a17

   SELECT DBUSERNAME, SQL_TEXT, AUDIT_TYPE
   FROM UNIFIED_AUDIT_TRAIL
   WHERE OBJECT_SCHEMA = 'HR' AND OBJECT_NAME = 'EMPLOYEES';


   Output similar to the following appears:

   DBUSERNAME  SQL_TEXT                                                          AUDIT_TYPE
   ----------  ----------------------------------------------------------------- ----------------
   SMAVRIS     UPDATE HR.EMPLOYEES SET SALARY = 38000 WHERE LAST_NAME = 'Mavris' FineGrainedAudit


   The audit trail captures the SQL statement that Susan Mavris ran that affected the SALARY column in the HR.EMPLOYEES table. The first statement she ran, in which she asked about her current salary, was not recorded because it was not affected by the audit policy. This is because Oracle Database executes the audit function as an autonomous transaction, committing only the actions of the handler_module setting and not any user transaction. The function has no effect on any user SQL transaction.

If you no longer need the components of this tutorial, then you can remove them.

1. Connect to SQL*Plus as user SYSTEM privilege, and then drop users fga_admin (including the objects in the fga_admin schema), fga_auditor, and smavris.

   CONNECT SYSTEM -- Or, CONNECT SYSTEM@hrpdb
   Enter password: password

   DROP USER fga_admin CASCADE;
   DROP USER fga_auditor;
   DROP USER smavris;


2. Connect as user HR and remove the loftiness of Susan Mavris's salary.

   CONNECT HR -- Or, CONNECT HR@hrpdb
   Enter password: password

   UPDATE HR.EMPLOYEES SET SALARY = 6500 WHERE LAST_NAME = 'Mavris';


3. If you want, lock and expire HR, unless other users want to use this account:

   ALTER USER HR PASSWORD EXPIRE ACCOUNT LOCK;


4. Issue the following ALTER SYSTEM statement to restore the SMTP_OUT_SERVER parameter to the previous value, from Step 5 under Step 1: Install and Configure the UTL_MAIL PL/SQL Package:

   ALTER SYSTEM SET SMTP_OUT_SERVER="previous_value";


   Enclose this setting in quotation marks. For example:

   ALTER SYSTEM SET SMTP_OUT_SERVER="some_imap_server.example.com"


5. Restart the database instance.
